DELIXI CDJ1-S-132KW CDJ1 Motor Soft Starter
- Brand
- DELIXI
- Model
- CDJ1-S-132KW
- GEARWELL SKU
- GWP-000021116
- Category
- Contactors & Starters
Key specifications
- Version
- CDJ1-S integrated type, frame CDJ1075S–CDJ1165S (75–165 kW, 140–300 A)
- Seller code
- CDJ1S132
- Frame weight
- 130 kg
- Rated current
- 240 A (132 kW rating in CDJ1 table)
- Starting modes
- Voltage ramp, current limit, heavy-load, full-voltage start; soft stop
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDJ1-S-132KW CDJ1 Motor Soft Starter |
|---|---|
| Brand | DELIXI |
| Model | CDJ1-S-132KW |
| Category | Contactors & Starters |
| Version | CDJ1-S integrated type, frame CDJ1075S–CDJ1165S (75–165 kW, 140–300 A) |
| Seller code | CDJ1S132 |
| Frame weight | 130 kg |
| Rated current | 240 A (132 kW rating in CDJ1 table) |
| Starting modes | Voltage ramp, current limit, heavy-load, full-voltage start; soft stop |
| Applicable motor | Three-phase squirrel-cage induction motor |
| Rated motor power | 132 kW |
| Rated supply voltage | AC 380 V, 50 Hz ±10% |
| Utilization category | AC-53b |
| Frame dimensions (W×D×H) | 560 × 600 × 1600 (frame CDJ1075S–CDJ1165S) mm |
