DELIXI CDJ1-S-17KW CDJ1 Wall-Mounted Motor Soft Starter
- Brand
- DELIXI
- Model
- CDJ1-S-17KW
- GEARWELL SKU
- GWP-000021117
- Category
- Contactors & Starters
Key specifications
- Weight
- 11 kg
- Version
- CDJ1-S wall-mounted type (frame CDJ1005S–CDJ1037S, 5.5–37 kW)
- Seller code
- CDJ1S117
- Rated current
- 10–34 A (5.5–17 kW frame)
- Starting modes
- Voltage ramp, current limit, heavy-load, full-voltage start; soft stop
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDJ1-S-17KW CDJ1 Wall-Mounted Motor Soft Starter |
|---|---|
| Brand | DELIXI |
| Model | CDJ1-S-17KW |
| Category | Contactors & Starters |
| Weight | 11 kg |
| Version | CDJ1-S wall-mounted type (frame CDJ1005S–CDJ1037S, 5.5–37 kW) |
| Seller code | CDJ1S117 |
| Rated current | 10–34 A (5.5–17 kW frame) |
| Starting modes | Voltage ramp, current limit, heavy-load, full-voltage start; soft stop |
| Circuit breaker | Supplied by user (CDJ1-S wall-mounted below 75 kW) |
| Applicable motor | Three-phase squirrel-cage induction motor |
| Dimensions (W×H×D) | 250 × 350 × 180 (frame CDJ1005S–CDJ1037S) mm |
| Rated motor power | 17 kW |
| Rated supply voltage | AC 380 V, 50 Hz ±10% |
| Utilization category | AC-53b |
