DELIXI JD-6Q 10A-80A AC220V JD-6 Motor Integrated Protector
- Brand
- DELIXI
- Model
- JD-6Q 10A-80A AC220V
- GEARWELL SKU
- GWP-000021235
- Category
- Contactors & Starters
Key specifications
- Trip class
- 10A
- Seller code
- JD6Q80A220
- Current range
- 10-80 A
- Type designation
- JD-6 Q 80A 220
- Specification code
- Q = dedicated type for reduced-voltage starter cabinets
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI JD-6Q 10A-80A AC220V JD-6 Motor Integrated Protector |
|---|---|
| Brand | DELIXI |
| Model | JD-6Q 10A-80A AC220V |
| Category | Contactors & Starters |
| Trip class | 10A |
| Seller code | JD6Q80A220 |
| Current range | 10-80 A |
| Type designation | JD-6 Q 80A 220 |
| Specification code | Q = dedicated type for reduced-voltage starter cabinets |
| Ambient temperature | -5 to +40 °C |
| Phase-loss protection | any phase lost: trip <= 3 s |
| Standard / certification | GB 14048.4 / CCC |
| Auxiliary contact rating | AC-15, Ue AC220V, Ie 0.47 A |
| Control supply voltage Us | AC 220 V |
