GE 12HFA51A42H HFA51 Multi-Contact Auxiliary Relay
- Brand
- GE
- Model
- 12HFA51A42H
- GEARWELL SKU
- GWP-000025144
- Category
- Contactors & Starters
Key specifications
- Type
- HFA51A, self-reset, instantaneous dropout
- Code suffix "H"
- as collected; not decoded in the opened instruction book (GEH-2024F)
- Contact circuits
- 6 electrically separate
- Coil ratings available
- AC up to 575 V (25/50/60 Hz), DC up to 250 V
- Contact closing rating
- 30 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE 12HFA51A42H HFA51 Multi-Contact Auxiliary Relay |
|---|---|
| Brand | GE |
| Model | 12HFA51A42H |
| Category | Contactors & Starters |
| Type | HFA51A, self-reset, instantaneous dropout |
| Code suffix "H" | as collected; not decoded in the opened instruction book (GEH-2024F) |
| Contact circuits | 6 electrically separate |
| Coil ratings available | AC up to 575 V (25/50/60 Hz), DC up to 250 V |
| Contact closing rating | 30 A |
| Contact carrying rating | 12 A continuous / 30 A for 1 min |
| Contact arrangement code | 42 (4 normally open, 2 normally closed) |
| Interrupting capacity at 125 VDC (non-inductive) | 3 A |
