OMRON G5V-1 DC5 G5V-1 Signal Relay
- Brand
- OMRON
- Model
- G5V-1 DC5
- GEARWELL SKU
- GWP-000024796
- Category
- Contactors & Starters
Key specifications
- Enclosure
- Fully sealed
- Rated load
- 0.5 A at 125 VAC; 1 A at 24 VDC
- Contact form
- SPDT (1c)
- Coil resistance
- 167 Ω
- Contact material
- Au-alloy + Ag
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | OMRON G5V-1 DC5 G5V-1 Signal Relay |
|---|---|
| Brand | OMRON |
| Model | G5V-1 DC5 |
| Category | Contactors & Starters |
| Enclosure | Fully sealed |
| Rated load | 0.5 A at 125 VAC; 1 A at 24 VDC |
| Contact form | SPDT (1c) |
| Coil resistance | 167 Ω |
| Contact material | Au-alloy + Ag |
| Rated coil current | 30 mA |
| Rated coil voltage | 5 VDC |
| Dimensions (L x W x H) | 12.5 x 7.5 x 10 mm |
