DELIXI CDS10-M/300 AC380V CDS10 Intelligent Motor Protector
- Brand
- DELIXI
- Model
- CDS10-M/300 AC380V
- GEARWELL SKU
- GWP-000021132
- Category
- Contactors & Starters
Key specifications
- Mounting
- M = panel mounting
- Seller code
- CDS10M300A380
- Certification
- CCC
- Contact rating
- 380 V 3 A / 220 V 5 A AC
- Type designation
- CDS10-M/300
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDS10-M/300 AC380V CDS10 Intelligent Motor Protector |
|---|---|
| Brand | DELIXI |
| Model | CDS10-M/300 AC380V |
| Category | Contactors & Starters |
| Mounting | M = panel mounting |
| Seller code | CDS10M300A380 |
| Certification | CCC |
| Contact rating | 380 V 3 A / 220 V 5 A AC |
| Type designation | CDS10-M/300 |
| Current transformer | external 500A/5A (class 0.5) |
| Suitable motor power | 30-70 kW |
| Max. operating current | 300 A |
| Rated control supply voltage | 380 V AC |
| Phase-loss / locked-rotor trip time | <= 0.5 s |
