DELIXI CDK163M606ML1 CDK1-63 6A Earth-Leakage CPS Switch
- Brand
- DELIXI
- Model
- CDK163M606ML1
- GEARWELL SKU
- GWP-000021128
- Category
- Contactors & Starters
Key specifications
- Standard
- IEC 60947-6-2 / GB 14048.9
- Control voltage
- AC 220 V (code M)
- Controller type M
- Digital tube type
- Frame current Inm
- 63 A
- Earth-leakage protection
- L1: 30 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDK163M606ML1 CDK1-63 6A Earth-Leakage CPS Switch |
|---|---|
| Brand | DELIXI |
| Model | CDK163M606ML1 |
| Category | Contactors & Starters |
| Standard | IEC 60947-6-2 / GB 14048.9 |
| Control voltage | AC 220 V (code M) |
| Controller type M | Digital tube type |
| Frame current Inm | 63 A |
| Earth-leakage protection | L1: 30 mA |
| Auxiliary contact code 06 | 3 NO + 3 NC + 1 short-circuit + 1 overload signal |
| Rated operational voltage | 380 V |
| Controller rated current Ie | 6 (setting range 2.4–6 A) A |
| Controlled motor power (AC-44, 380 V) | 1–2.5 kW |
| Rated service breaking capacity Ics | 15 kA |
