DELIXI CDS10-M/150 AC220V CDS10 Intelligent Motor Protector
- Brand
- DELIXI
- Model
- CDS10-M/150 AC220V
- GEARWELL SKU
- GWP-000021130
- Category
- Circuit Protection
Key specifications
- Seller code
- CDS10M150A220
- Installation
- M: panel type
- Certification
- CCC
- Contact rating
- AC 380 V 3 A / AC 220 V 5 A
- Current transformer
- External 300 A/5 A (class 0.5)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | DELIXI CDS10-M/150 AC220V CDS10 Intelligent Motor Protector |
|---|---|
| Brand | DELIXI |
| Model | CDS10-M/150 AC220V |
| Category | Circuit Protection |
| Seller code | CDS10M150A220 |
| Installation | M: panel type |
| Certification | CCC |
| Contact rating | AC 380 V 3 A / AC 220 V 5 A |
| Current transformer | External 300 A/5 A (class 0.5) |
| Applicable motor power | 3–30 kW |
| Motor overload trip time | 30–600 s |
| Maximum operating current | 150 A |
| Rated control supply voltage | AC 220 V |
| Phase-loss / locked-rotor / short-circuit trip time | ≤ 0.5 s |
