BECKHOFF KL9182 Potential Distribution Terminal, 2 x 8 Potentials
- Brand
- BECKHOFF
- Model
- KL9182
- GEARWELL SKU
- GWP-000008293
- Category
- PLCs & I/O
Key specifications
- Weight
- approx. 60 g
- Current load
- max. 10 A (per terminal point)
- Nominal voltage
- ≤ 60 V AC/DC
- Electrical isolation
- 500 V (K-bus/field potential)
- K-bus, looped through
- yes
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
Beckhoff KL9182 is a potential distribution terminal with 8 separate potentials of 2 terminal points each (up to 60 V AC/DC, 10 A per terminal point). It passes the K-bus and power contacts through. Check the full order number, including any suffix, on the terminal when requesting a quote.
Technical reference
| Product name | BECKHOFF KL9182 Potential Distribution Terminal, 2 x 8 Potentials |
|---|---|
| Brand | BECKHOFF |
| Model | KL9182 |
| Category | PLCs & I/O |
| Weight | approx. 60 g |
| Current load | max. 10 A (per terminal point) |
| Nominal voltage | ≤ 60 V AC/DC |
| Electrical isolation | 500 V (K-bus/field potential) |
| K-bus, looped through | yes |
| Number of separate potentials | 8 |
| Power contacts looped through | yes (2 power contacts) |
| Terminal points per potential | 2 |
