BAUMER MEX5-D62.B77 MEX5 Industrial Pressure Gauge
- Brand
- BAUMER
- Model
- MEX5-D62.B77
- GEARWELL SKU
- GWP-000021898
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy
- class 1 (EN 837-1)
- Evidence
- Baumer data sheet A21.24 MEX5 - MEM5 (hosted at static.chipdip.ru)
- Nominal size
- 100 mm
- Protection rating
- IP65 (EN 60529)
- Liquid filling (code 2)
- BH2 high-viscosity glycerin 99.5% (medium 0 ... +90 °C)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER MEX5-D62.B77 MEX5 Industrial Pressure Gauge |
|---|---|
| Brand | BAUMER |
| Model | MEX5-D62.B77 |
| Category | Pressure, Flow & Temperature |
| Accuracy | class 1 (EN 837-1) |
| Evidence | Baumer data sheet A21.24 MEX5 - MEM5 (hosted at static.chipdip.ru) |
| Nominal size | 100 mm |
| Protection rating | IP65 (EN 60529) |
| Liquid filling (code 2) | BH2 high-viscosity glycerin 99.5% (medium 0 ... +90 °C) |
| Pressure range (code B77) | -1 ... 5 bar |
| Type of mounting (code D) | bottom connection, stainless steel case and bezel ring 1.4301 |
| Process connection (code 6) | 1/2 NPT |
| Bourdon tube / process connection material | stainless steel 1.4404 (AISI 316L) |
