BAUMER MEX5-D61.B22 MEX5 Industrial Pressure Gauge
- Brand
- BAUMER
- Model
- MEX5-D61.B22
- GEARWELL SKU
- GWP-000021887
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- MEX5 industrial pressure gauge, nominal size 100 mm, stainless steel wetted parts
- Accuracy
- Class 1 (EN 837-1)
- Evidence
- Baumer data sheet A21.24 MEX5 - MEM5 (2015-07-03, hosted at static.chipdip.ru)
- Seller code
- MEX5D61B22
- Protection rating
- IP 65 (EN 60529)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER MEX5-D61.B22 MEX5 Industrial Pressure Gauge |
|---|---|
| Brand | BAUMER |
| Model | MEX5-D61.B22 |
| Category | Pressure, Flow & Temperature |
| Series | MEX5 industrial pressure gauge, nominal size 100 mm, stainless steel wetted parts |
| Accuracy | Class 1 (EN 837-1) |
| Evidence | Baumer data sheet A21.24 MEX5 - MEM5 (2015-07-03, hosted at static.chipdip.ru) |
| Seller code | MEX5D61B22 |
| Protection rating | IP 65 (EN 60529) |
| Liquid filling (code 1) | BH1: glycerin/water 86 %, low viscosity (medium -20 … +70 °C) |
| Pressure range (code B22) | 0 … 10 bar |
| Type of mounting (code D) | Bottom connection; case and bezel ring stainless steel 1.4301 (AISI 304) |
| Process connection (code 6) | 1/2 NPT |
| Bourdon tube / process connection material | Stainless steel 1.4404 (AISI 316L) |
