BAUMER MAT5DX(M20x1.5)0B24(oxygen) MAT Pressure Gauge, 100 mm
- Brand
- BAUMER
- Model
- MAT5DX(M20x1.5)0B24(oxygen)
- GEARWELL SKU
- GWP-000020603
- Category
- Pressure, Flow & Temperature
Key specifications
- Case
- Black painted steel
- Accuracy
- ± 2.5 % of full scale
- Nominal size
- 100 mm
- Product line
- Bourdon pressure gauges (Baumer group)
- Measuring range
- 0 ... 16 bar
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER MAT5DX(M20x1.5)0B24(oxygen) MAT Pressure Gauge, 100 mm |
|---|---|
| Brand | BAUMER |
| Model | MAT5DX(M20x1.5)0B24(oxygen) |
| Category | Pressure, Flow & Temperature |
| Case | Black painted steel |
| Accuracy | ± 2.5 % of full scale |
| Nominal size | 100 mm |
| Product line | Bourdon pressure gauges (Baumer group) |
| Measuring range | 0 ... 16 bar |
| Sensing element | Cupreous metal Bourdon tube |
| Type designation | MAT5DX(M20x1.5)0B24(oxygen) |
| Type of mounting | Bottom connection (D) |
| Code suffix "(oxygen)" | as collected; oxygen-service execution not listed in the official model-number table |
| Process connection | M20 x 1.5 (special connection, code X) |
| Degree of protection | IP 32 |
| Code position "X(M20x1.5)" | as collected; special male thread out of the standard table (standard for Ø100 is G 1/2) |
