BAUMER IFFM 08P17A6/L Inductive Proximity Sensor, Subminiature 8 mm
- Brand
- BAUMER
- Model
- IFFM 08P17A6/L
- GEARWELL SKU
- GWP-000020602
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Rectangular 8 mm, die-cast zinc nickel plated, length 16 mm
- Mounting type
- Flush
- Article number
- 10142377
- Output circuit
- PNP make function (NO)
- Output current
- 100 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER IFFM 08P17A6/L Inductive Proximity Sensor, Subminiature 8 mm |
|---|---|
| Brand | BAUMER |
| Model | IFFM 08P17A6/L |
| Category | Proximity & Photoelectric Sensors |
| Housing | Rectangular 8 mm, die-cast zinc nickel plated, length 16 mm |
| Mounting type | Flush |
| Article number | 10142377 |
| Output circuit | PNP make function (NO) |
| Output current | 100 mA |
| Connection type | Cable, L=2 m |
| Protection class | IP 67 |
| Type designation | IFFM 08P17A6/L |
| Switching frequency | 5 kHz |
| Voltage supply range | 6 … 30 VDC |
| Nominal sensing distance Sn | 2 mm |
