BAUMER HEAG171 TTL ST 65 LWL-Transmitter Fiber-Optic Transmitter
- Brand
- BAUMER
- Model
- HEAG171 TTL ST 65 LWL-Transmitter
- GEARWELL SKU
- GWP-000020601
- Category
- Encoders & Position
Key specifications
- Inputs
- 4 x TTL (K1, K2, K3, K4 + inverted)
- Outputs
- 4 x fiber-optic
- Voltage supply
- 9...26 VDC
- Code suffix "TTL"
- as collected; not listed in the official model-number table
- Type designation
- HEAG171 TTL ST 65 LWL-Transmitter
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER HEAG171 TTL ST 65 LWL-Transmitter Fiber-Optic Transmitter |
|---|---|
| Brand | BAUMER |
| Model | HEAG171 TTL ST 65 LWL-Transmitter |
| Category | Encoders & Position |
| Inputs | 4 x TTL (K1, K2, K3, K4 + inverted) |
| Outputs | 4 x fiber-optic |
| Voltage supply | 9...26 VDC |
| Code suffix "TTL" | as collected; not listed in the official model-number table |
| Type designation | HEAG171 TTL ST 65 LWL-Transmitter |
| Protection EN 60529 | IP 65 |
| Transmission length | ≤300 m |
| Dimensions W x H x L | 122 x 122 x 80 mm |
| Transmission frequency | ≤250 kHz |
| Reference version on baumer.com | HEAG171 R ST 65 LWL-Transmitter (art. 11064707) |
