BANNER 73544 LS2TP30-150Q88 EZ-SCREEN Type 2 Safety Light Curtain
- Brand
- BANNER
- Model
- 73544
- GEARWELL SKU
- GWP-000014145
- Category
- Machine Safety & Vision
Key specifications
- Resolution
- 30 mm
- OSSD rating
- 24 V dc at 0.5 A each
- Part number
- 73544
- Safety level
- Type 2 per IEC 61496-2; SIL2; CL2
- Response time
- 11 ms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BANNER 73544 LS2TP30-150Q88 EZ-SCREEN Type 2 Safety Light Curtain |
|---|---|
| Brand | BANNER |
| Model | 73544 |
| Category | Machine Safety & Vision |
| Resolution | 30 mm |
| OSSD rating | 24 V dc at 0.5 A each |
| Part number | 73544 |
| Safety level | Type 2 per IEC 61496-2; SIL2; CL2 |
| Response time | 11 ms |
| Supply voltage | 24 V dc |
| Type designation | LS2TP30-150Q88 |
| Operating distance | 0.2 - 15 m |
| Defined area height | 150 mm |
| Overall length / connection | 215 mm / 8-pin M12, IP65 |
