B&R 5AP1120.0702-000 Automation Panel 7" Touch Display Panel
- Brand
- B&R
- Model
- 5AP1120.0702-000
- GEARWELL SKU
- GWP-000033324
- Category
- HMIs & Industrial PCs
Key specifications
- For
- AP1000, PPC2100, PPC2200 / link modules
- Display
- 7.0" TFT color, WVGA 800 x 480
- Contrast
- 550:1
- Brightness
- typ. 80 to 500 cd/m² (dimmable)
- Protection
- Front IP65, back IP20
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | B&R 5AP1120.0702-000 Automation Panel 7" Touch Display Panel |
|---|---|
| Brand | B&R |
| Model | 5AP1120.0702-000 |
| Category | HMIs & Industrial PCs |
| For | AP1000, PPC2100, PPC2200 / link modules |
| Display | 7.0" TFT color, WVGA 800 x 480 |
| Contrast | 550:1 |
| Brightness | typ. 80 to 500 cd/m² (dimmable) |
| Protection | Front IP65, back IP20 |
| Touch screen | Single-touch, analog resistive |
| Certifications | CE, UKCA, cULus, cULus HazLoc |
| Material number | 5AP1120.0702-000 |
