AZBIL MPC0005BBRN0100D0 MPC Panel Mount Mass Flow Controller
- Brand
- AZBIL
- Model
- MPC0005BBRN0100D0
- GEARWELL SKU
- GWP-000016505
- Category
- Pressure, Flow & Temperature
Key specifications
- Display
- Integrated display
- Accuracy
- Within ±2 % FS
- Gas type
- Air/nitrogen, argon, carbon dioxide
- Response
- Within 1.0 s at setting ±2 % FS (typical)
- Connection
- Rc 1/8
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL MPC0005BBRN0100D0 MPC Panel Mount Mass Flow Controller |
|---|---|
| Brand | AZBIL |
| Model | MPC0005BBRN0100D0 |
| Category | Pressure, Flow & Temperature |
| Display | Integrated display |
| Accuracy | Within ±2 % FS |
| Gas type | Air/nitrogen, argon, carbon dioxide |
| Response | Within 1.0 s at setting ±2 % FS (typical) |
| Connection | Rc 1/8 |
| Certificate | With test data (D) |
| Power supply | 24 V DC, 300 mA max. |
| Flow rate range | 0.10 to 5.00 L/min (standard) |
| Optional function | Analog input/output and event output |
| Gas-contacting material | Brass (Ni-plated) |
