AZBIL MQV0500KSSN000000 MQV Digital Mass Flow Controller
- Brand
- AZBIL
- Model
- MQV0500KSSN000000
- GEARWELL SKU
- GWP-000021621
- Category
- Pressure, Flow & Temperature
Key specifications
- Display
- Separate display (body length 150 mm)
- Gas type
- Air / nitrogen
- Connection
- 1/2" Swagelok
- Power supply
- 24 V DC
- Body material
- SUS316
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AZBIL MQV0500KSSN000000 MQV Digital Mass Flow Controller |
|---|---|
| Brand | AZBIL |
| Model | MQV0500KSSN000000 |
| Category | Pressure, Flow & Temperature |
| Display | Separate display (body length 150 mm) |
| Gas type | Air / nitrogen |
| Connection | 1/2" Swagelok |
| Power supply | 24 V DC |
| Body material | SUS316 |
| Optional functions | None |
| Accuracy (standard model) | ±0.5 % FS (≤40 % FS), ±1 % FS (40–80 % FS), ±1.5 % FS (>80 % FS) |
| Control flow rate range | 4 to 500 L/min (standard) |
| Allowable inlet pressure | -0.07 to 0.5 MPa (gauge) |
| Required differential pressure | 150 kPa |
