AUTONICS TC4W-14R TC Series Single Display PID Temperature Controller

Key specifications

Size: DIN W96 x H48 mm
Option output: Alarm 1
Power voltage: 100-240VAC 50/60Hz
Control method: ON/OFF, P, PI, PD, PID
Control output: Relay (250VAC 3A) or SSR drive (12VDC) [ON/OFF, phase, cycle]

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	AUTONICS TC4W-14R TC Series Single Display PID Temperature Controller
Brand	AUTONICS
Model	TC4W-14R
Category	Pressure, Flow & Temperature
Size	DIN W96 x H48 mm
Option output	Alarm 1
Power voltage	100-240VAC 50/60Hz
Control method	ON/OFF, P, PI, PD, PID
Control output	Relay (250VAC 3A) or SSR drive (12VDC) [ON/OFF, phase, cycle]
Display method	4-digit 7-segment LED
Sampling cycle	100 ms
Proportional band	0.1 to 999.9℃/℉
Input specification	Thermocouple K(CA), J(IC), L(IC); RTD DPt100Ω, Cu50Ω
