AUTONICS TC3YT-B4R16 TC3YT Digital Temperature Controller
- Brand
- AUTONICS
- Model
- TC3YT-B4R16
- GEARWELL SKU
- GWP-000021928
- Category
- Pressure, Flow & Temperature
Key specifications
- Evidence
- Autonics TC3YT Series product manual TCD210159AA (hosted at baa.vn)
- Unit weight
- ≈ 103 g
- Power supply
- 100-240VAC 50/60Hz ±10%
- Control method
- ON/OFF, proportional control
- Display method
- 3-digit 7-segment LED
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TC3YT-B4R16 TC3YT Digital Temperature Controller |
|---|---|
| Brand | AUTONICS |
| Model | TC3YT-B4R16 |
| Category | Pressure, Flow & Temperature |
| Evidence | Autonics TC3YT Series product manual TCD210159AA (hosted at baa.vn) |
| Unit weight | ≈ 103 g |
| Power supply | 100-240VAC 50/60Hz ±10% |
| Control method | ON/OFF, proportional control |
| Display method | 3-digit 7-segment LED |
| Sampling period | 500 ms |
| Input specification | Thermocouple K(CA) 0-999℃, J(IC) 0-400℃; RTD DPt100Ω (Pt H 0-400℃, Pt L -99-199℃) |
| Protection structure | IP65 (front panel) |
| Control output (relay type) | 250VAC 16A 1c |
