AUTONICS MX4W-V-FN MX4W LCD Multi Panel Meter AC/DC Voltage
- Brand
- AUTONICS
- Model
- MX4W-V-FN
- GEARWELL SKU
- GWP-000016441
- Category
- Test & Measurement
Key specifications
- Main output
- Indicator
- Measurement
- DC voltage, AC voltage, frequency
- Rear length
- 20 mm
- Display cycle
- 0.2 to 5.0 s (0.1 s steps)
- Power voltage
- 24-240VAC 50/60Hz, 24-240VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS MX4W-V-FN MX4W LCD Multi Panel Meter AC/DC Voltage |
|---|---|
| Brand | AUTONICS |
| Model | MX4W-V-FN |
| Category | Test & Measurement |
| Main output | Indicator |
| Measurement | DC voltage, AC voltage, frequency |
| Rear length | 20 mm |
| Display cycle | 0.2 to 5.0 s (0.1 s steps) |
| Power voltage | 24-240VAC 50/60Hz, 24-240VDC |
| AC measurement | RMS / AVG selectable |
| Character height | 19 mm |
| Max. display range | -9999 to 9999 (4 digit) |
| Input specification | DC ±500mV, ±200mV, ±50mV, ±20V, ±5V, 1-5V, ±2V, ±500V, ±200V, ±50V; AC 0-500mV, 0-200mV, 0-50mV, 0-20V, 0-5V, 0-2V, 0-500V, 0-200V, 0-110V, 0-50V |
| Protection structure | IP54 (front part, IEC standard) |
