AUTONICS MT4Y-DV-43 MT4Y Digital Panel Meter DC Voltage
- Brand
- AUTONICS
- Model
- MT4Y-DV-43
- GEARWELL SKU
- GWP-000016440
- Category
- Test & Measurement
Key specifications
- Measurement
- DC voltage
- Power voltage
- 100-240VAC 50/60Hz
- Display method
- 4-digit 7-segment LED
- Sampling cycle
- 50 ms
- Character height
- 14.2 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS MT4Y-DV-43 MT4Y Digital Panel Meter DC Voltage |
|---|---|
| Brand | AUTONICS |
| Model | MT4Y-DV-43 |
| Category | Test & Measurement |
| Measurement | DC voltage |
| Power voltage | 100-240VAC 50/60Hz |
| Display method | 4-digit 7-segment LED |
| Sampling cycle | 50 ms |
| Character height | 14.2 mm |
| Max. display range | -1999 to 9999 |
| Input specification | 0-500V, 0-100V, 0-50V, 0-10V, 0-5V, 0-1V, 0-250mV, 0-50mV |
| Protection structure | IP56 (front part, IEC standard) |
| Sub output (display value) | PV transmission(DC4-20mA) |
| Main output (comparative value) | Relay (LOW OUT) |
