AUTONICS MX4W-A-F2 MX4W LCD Multi Panel Meter AC/DC Current
- Brand
- AUTONICS
- Model
- MX4W-A-F2
- GEARWELL SKU
- GWP-000021385
- Category
- Test & Measurement
Key specifications
- Main output
- PNP open collector output
- Measurement
- DC current, AC current, frequency
- Rear length
- 20 mm
- Display cycle
- 0.2 to 5.0 s (0.1 s steps)
- Power voltage
- 24-240VAC 50/60Hz, 24-240VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS MX4W-A-F2 MX4W LCD Multi Panel Meter AC/DC Current |
|---|---|
| Brand | AUTONICS |
| Model | MX4W-A-F2 |
| Category | Test & Measurement |
| Main output | PNP open collector output |
| Measurement | DC current, AC current, frequency |
| Rear length | 20 mm |
| Display cycle | 0.2 to 5.0 s (0.1 s steps) |
| Power voltage | 24-240VAC 50/60Hz, 24-240VDC |
| AC measurement | RMS / AVG selectable |
| Character height | 19 mm |
| Max. display range | -9999 to 9999 (4 digit) |
| Input specification | DC ±20mA, 4-20mA, ±5mA, ±2mA, ±500mA, ±200mA, ±50mA, ±5A, ±2A; AC 0-20mA, 0-5mA, 0-2mA, 0-500mA, 0-200mA, 0-50mA, 0-5A, 0-2A |
| Protection structure | IP54 (front part, IEC standard) |
