AUTONICS E50S8-600-3-T-24 E50S Incremental Rotary Encoder
- Brand
- AUTONICS
- Model
- E50S8-600-3-T-24
- GEARWELL SKU
- GWP-000021382
- Category
- Encoders & Position
Key specifications
- Resolution
- 600P/R
- Output phase
- A, B, Z
- Power voltage
- 12-24VDC ±5%(ripple P-P: max. 5%)
- Control output
- Totem pole
- Connection type
- Axial cable type
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS E50S8-600-3-T-24 E50S Incremental Rotary Encoder |
|---|---|
| Brand | AUTONICS |
| Model | E50S8-600-3-T-24 |
| Category | Encoders & Position |
| Resolution | 600P/R |
| Output phase | A, B, Z |
| Power voltage | 12-24VDC ±5%(ripple P-P: max. 5%) |
| Control output | Totem pole |
| Connection type | Axial cable type |
| Protection rating | IP50 (IEC standard) |
| Shaft outer diameter | Ø8mm |
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
