AUTONICS E40S6-600-3-T-24 3M E40S Incremental Rotary Encoder
- Brand
- AUTONICS
- Model
- E40S6-600-3-T-24 3M
- GEARWELL SKU
- GWP-000021380
- Category
- Encoders & Position
Key specifications
- Base model
- E40S6-600-3-T-24
- Resolution
- 600P/R
- Output phase
- A, B, Z
- Power voltage
- 12-24VDC ±5%(ripple P-P: max. 5%)
- Code suffix "3M"
- as collected; not listed in the official model-number table
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS E40S6-600-3-T-24 3M E40S Incremental Rotary Encoder |
|---|---|
| Brand | AUTONICS |
| Model | E40S6-600-3-T-24 3M |
| Category | Encoders & Position |
| Base model | E40S6-600-3-T-24 |
| Resolution | 600P/R |
| Output phase | A, B, Z |
| Power voltage | 12-24VDC ±5%(ripple P-P: max. 5%) |
| Code suffix "3M" | as collected; not listed in the official model-number table |
| Control output | Totem pole |
| Connection type | Radial cable type |
| Protection rating | IP50 |
| Shaft outer diameter | Ø6mm |
| Max. response frequency | 300kHz |
| Max. allowable revolution | 5000rpm |
