AUTONICS E40S6-360-3-N-24 E40S Incremental Rotary Encoder
- Brand
- AUTONICS
- Model
- E40S6-360-3-N-24
- GEARWELL SKU
- GWP-000023604
- Category
- Encoders & Position
Key specifications
- Weight
- approx. 120 g
- Resolution
- 360 P/R
- Output phase
- A, B, Z
- Power voltage
- 12-24 VDC
- Control output
- NPN open collector
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS E40S6-360-3-N-24 E40S Incremental Rotary Encoder |
|---|---|
| Brand | AUTONICS |
| Model | E40S6-360-3-N-24 |
| Category | Encoders & Position |
| Weight | approx. 120 g |
| Resolution | 360 P/R |
| Output phase | A, B, Z |
| Power voltage | 12-24 VDC |
| Control output | NPN open collector |
| Connection type | Radial cable |
| Protection structure | IP50 |
| Shaft outer diameter | 6 mm |
| Max. response frequency | 300 kHz |
| Max. allowable revolution | 5000 rpm |
