Allen-Bradley VPL-B1653D-QK12AS Kinetix VPL Low-Inertia Servo Motor

Product overview

The Allen-Bradley VPL-B1653D-QK12AS is a Kinetix VPL low-inertia servo motor for 400 V-class drives in the 165 mm frame, rated 5.50 kW at 3000 rpm (maximum 3000 rpm) with 24.20 N·m continuous stall torque and 67.80 N·m peak stall torque. This version has a 23-bit absolute multi-turn digital encoder (Hiperface DSL) rated SIL 2 (PLd), a smooth shaft, a single right-angle SpeedTec DIN connector that rotates through 325°, no holding brake, an IEC metric mounting flange and a shaft seal. With the shaft seal it reaches IP66 when used with Rockwell factory-delivered Kinetix 2090 cables. Rockwell matches VPL windings to Kinetix 5500 drives, Kinetix 5700 dual-axis inverters and ArmorKinetix DSD modules, with a single Kinetix 2090 cable between motor and drive, for packaging, converting, material handling, electronic assembly and automotive applications.
