Allen-Bradley 800T-A9A Yellow Flush Momentary Push Button
- Brand
- Allen-Bradley
- Model
- 800TA9A
- GEARWELL SKU
- GWP-000003011
- Category
- Industrial Automation Parts
Key specifications
- Type
- 30 mm non-illuminated momentary push button
- Illumination
- Non-illuminated
- Operator cap type
- Flush head
- Operator cap color
- Yellow
- Contact configuration
- 1 N.O. + 1 N.C. (800T-XA standard contact block)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 800T-A9A is an 800T 30.5 mm Type 4/13 momentary push button, non-illuminated, with a yellow flush head and 1 N.O. - 1 N.C. contacts, factory assembled.
Technical reference
| Product name | Allen-Bradley 800T-A9A Yellow Flush Momentary Push Button |
|---|---|
| Brand | Allen-Bradley |
| Model | 800TA9A |
| Category | Industrial Automation Parts |
| Type | 30 mm non-illuminated momentary push button |
| Illumination | Non-illuminated |
| Operator cap type | Flush head |
| Operator cap color | Yellow |
| Contact configuration | 1 N.O. + 1 N.C. (800T-XA standard contact block) |
| Operating temperature (800-TD009L) | -40 to +55 °C (non-illuminated; below freezing requires no moisture/liquids; minimum enclosure 110 x 80 x 70 mm) |
| Mounting hole diameter | 30.5 mm |
| Contact utilization categories | AC: A600 / AC-15; DC: Q600 / DC-13 |
| Enclosure compatibility (NEMA type) | 1, 4, 12, 13 |
| Contact block termination wire range | 14 - 18 AWG (x2) |
| Contact block continuous thermal current | 10 A AC / 2.5 A DC; not the rated switching current |
| Contact block operational voltage, maximum | 600 V AC / 600 V DC; load limits depend on utilization category |
| Contact block termination tightening torque | 6 - 8 in-lb / 0.7 - 0.9 N-m |
