Allen-Bradley 1794-ACNR15 FLEX I/O Redundant-Media ControlNet Adapter
- Brand
- Allen-Bradley
- Model
- 1794ACNR15
- GEARWELL SKU
- GWP-000003612
- Category
- PLCs & I/O
Key specifications
- I/O module capacity (Series D)
- Up to 8 FLEX I/O modules.
- Nominal supply voltage (Series D)
- 24 V DC
- Product type
- FLEX I/O redundant-media ControlNet adapter
- Input supply (Series D)
- 19.2…31.2 V DC; 400 mA.
- Flexbus output (Series D)
- 5 V DC; 640 mA.
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 1794-ACNR15 is a FLEX I/O ControlNet adapter that accepts redundant ControlNet cable media and connects up to 8 FLEX I/O modules at 5 Mbps over RG-6/U quad shield coax (1786-RG6). It runs on 24V DC (19.2…31.2V DC) and is rated for -20…+55 °C (-4…+131 °F).
Technical reference
| Product name | Allen-Bradley 1794-ACNR15 FLEX I/O Redundant-Media ControlNet Adapter |
|---|---|
| Brand | Allen-Bradley |
| Model | 1794ACNR15 |
| Category | PLCs & I/O |
| I/O module capacity (Series D) | Up to 8 FLEX I/O modules. |
| Nominal supply voltage (Series D) | 24 V DC |
| Product type | FLEX I/O redundant-media ControlNet adapter |
| Input supply (Series D) | 19.2…31.2 V DC; 400 mA. |
| Flexbus output (Series D) | 5 V DC; 640 mA. |
| Manufacturer lifecycle status | End of Life |
| Communication rate (Series D) | 5 Mbps |
| ControlNet connectors (Series D) | 2 BNC network connectors (channels A and B); redundant media. |
| Product description | ControlNet adapter with two BNC network connectors for redundant media. |
| Communication protocol | ControlNet V1.5; supports media redundancy. |
