Allen-Bradley 1756-ENBT ControlLogix EtherNet/IP Bridge Module
- Brand
- Allen-Bradley
- Model
- 1756ENBT
- GEARWELL SKU
- GWP-000000187
- Category
- PLCs & I/O
Key specifications
- Product type
- ControlLogix EtherNet/IP Bridge Module
- Enclosure type
- None (open-style)
- Product family
- ControlLogix 1756
- Backplane current
- 700 mA at 5.1 V DC; 3 mA at 24 V DC
- Network
- EtherNet/IP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 1756-ENBT is an EtherNet/IP bridge module from Rockwell's ControlLogix 1756 range. It links Logix 5000 controllers and communicates with devices on an EtherNet/IP network at 10/100 Mbps through one RJ45 port, with 64 TCP and 128 CIP connections, and draws 700 mA at 5.1 V DC. Rockwell lists it as end of life since November 1, 2021; the engineered replacement is the 1756-EN2T. It installs in any slot of a 1756 ControlLogix chassis and takes one slot.
Technical reference
| Product name | Allen-Bradley 1756-ENBT ControlLogix EtherNet/IP Bridge Module |
|---|---|
| Brand | Allen-Bradley |
| Model | 1756ENBT |
| Category | PLCs & I/O |
| Product type | ControlLogix EtherNet/IP Bridge Module |
| Enclosure type | None (open-style) |
| Product family | ControlLogix 1756 |
| Backplane current | 700 mA at 5.1 V DC; 3 mA at 24 V DC |
| Network | EtherNet/IP |
| CIP connections | 128 |
| TCP connections | 64 |
| EtherNet/IP communication rate | 10/100 Mbps |
| Ethernet interface | 1 RJ45 copper port |
| Communication rate | 10/100 Mbps |
