ABB SDCS-CON-2 DCS500B / DCS600 DC drive control board
- Brand
- ABB
- Model
- SDCS-CON-2
- GEARWELL SKU
- GWP-000029529
- Category
- Variable Frequency Drives
Key specifications
- Processor
- 80186EM microprocessor with ASIC DC94L01
- Serial channels
- 2x RS485
- Tacho input AITAC
- ±8...30 V / ±30...90 V / ±90...270 V, 12 bit + sign
- Analogue input AI1
- -10...0...+10 V, 12 bit + sign
- Analogue input AI2
- -10...0...+10 V, 11 bit + sign
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB SDCS-CON-2 DCS500B / DCS600 DC drive control board |
|---|---|
| Brand | ABB |
| Model | SDCS-CON-2 |
| Category | Variable Frequency Drives |
| Processor | 80186EM microprocessor with ASIC DC94L01 |
| Serial channels | 2x RS485 |
| Tacho input AITAC | ±8...30 V / ±30...90 V / ±90...270 V, 12 bit + sign |
| Analogue input AI1 | -10...0...+10 V, 12 bit + sign |
| Analogue input AI2 | -10...0...+10 V, 11 bit + sign |
| Pulse encoder input | 5 V or 12/24 V, single ended or differential (jumper S1) |
