ABB PP886H Panel 800 Version 6 Rugged marine operator panel, 15.4 in touch screen
- Brand
- ABB
- Model
- PP886H
- GEARWELL SKU
- GWP-000029455
- Category
- HMIs & Industrial PCs
Key specifications
- Weight
- 4.54 kg
- Display
- 15.4 in TFT-LCD with LED backlight, 1280 x 800 pixels, 1000 cd/m2
- Ethernet
- 1 x 10/100 Base-T, 1 x 10/100/1000 Base-T
- Power supply
- +12 V DC to +28 V DC (10 to 32 V DC)
- Front panel (W x H x D)
- 410 x 286 x 7 mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB PP886H Panel 800 Version 6 Rugged marine operator panel, 15.4 in touch screen |
|---|---|
| Brand | ABB |
| Model | PP886H |
| Category | HMIs & Industrial PCs |
| Weight | 4.54 kg |
| Display | 15.4 in TFT-LCD with LED backlight, 1280 x 800 pixels, 1000 cd/m2 |
| Ethernet | 1 x 10/100 Base-T, 1 x 10/100/1000 Base-T |
| Power supply | +12 V DC to +28 V DC (10 to 32 V DC) |
| Front panel (W x H x D) | 410 x 286 x 7 mm |
| Front / rear panel seal | IP65, NEMA-4X / IP20 |
| Operating temperature | -30 to +70 °C |
