ABB CP405 7" TFT touchscreen control panel
- Brand
- ABB
- Model
- CP405
- GEARWELL SKU
- GWP-000014870
- Category
- HMIs & Industrial PCs
Key specifications
- Display
- 7" TFT, touchscreen
- Net weight
- 0.6 kg
- Resolution
- 800 x 480 pixel
- Dimensions (W x H x D)
- 204.4 x 151 x 26.5 mm
- Lifecycle status (DESTO)
- Obsolete
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ABB CP405 is the CP405 control panel (order no. 1SAP500405R0001) with a 7” WVGA TFT touch screen of 800 x 480 pixels, 65,536 colors and LED backlight. It has a serial port for RS-232, RS-485 or RS422, a USB type A port for printers and accessories and a USB type B port for programming, 8 MB NOR + 128 MB NAND flash and a real-time clock. Supply is 24 VDC ± 10% at 10 W max., the front panel is rated IP66 and operating temperature is 0 … +50 °C.
Technical reference
| Product name | ABB CP405 7" TFT touchscreen control panel |
|---|---|
| Brand | ABB |
| Model | CP405 |
| Category | HMIs & Industrial PCs |
| Display | 7" TFT, touchscreen |
| Net weight | 0.6 kg |
| Resolution | 800 x 480 pixel |
| Dimensions (W x H x D) | 204.4 x 151 x 26.5 mm |
| Lifecycle status (DESTO) | Obsolete |
