ABB CC-U/I CC-U range signal converters Universal measuring converter for current RMS values
- Brand
- ABB
- Model
- CC-U/I
- GEARWELL SKU
- GWP-000029049
- Category
- Relays & Controllers
Key specifications
- Accuracy
- ±0.5 % of full-scale
- Output signal
- 0-20 mA, 4-20 mA, 0-5 V, 1-5 V, 0-10 V, 2-10 V, ±10 V
- Response time
- 150 ms
- Power consumption
- 2 W at 24 V DC
- Rated input range
- 0-1 / 0-5 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ABB CC-U/I CC-U range signal converters Universal measuring converter for current RMS values |
|---|---|
| Brand | ABB |
| Model | CC-U/I |
| Category | Relays & Controllers |
| Accuracy | ±0.5 % of full-scale |
| Output signal | 0-20 mA, 4-20 mA, 0-5 V, 1-5 V, 0-10 V, 2-10 V, ±10 V |
| Response time | 150 ms |
| Power consumption | 2 W at 24 V DC |
| Rated input range | 0-1 / 0-5 A |
| Measuring frequency | 0-600 Hz |
| Rated supply voltage | 24-48 V DC |
| Ambient temperature (operation) | -20...+60 °C |
