ABB ACS380-040S-05A6-4 Frequency Inverter
- Brand
- ABB
- Model
- ACS380-040S-05A6-4
- GEARWELL SKU
- GWP-000003628
- Category
- Electrical, Power & Connectivity
Key specifications
- Frame size
- R1
- Supply voltage
- 3-phase 380 to 480 V AC
- Heavy-duty rating
- 1.5 kW, 4.0 A
- Light-duty rating
- 2.2 kW, 5.3 A
- ABB order code
- 3AXD50000031890
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ABB ACS380-040S-05A6-4 is an ACS380 machinery drive for three-phase 380–480 V supplies, rated 2.2 kW in nominal and light-duty use and 1.5 kW in heavy-duty use, with 5.6 A nominal output current, in frame R1. In the type code, 04 is the module construction for cabinet installation (IP20), 0 is the low EMC filtering level (a category C3 EMC filter on this voltage) and S is the standard variant with the BMIO-01 I/O and Modbus module. ABB designs the ACS380 to control induction motors, permanent magnet synchronous motors and ABB SynRM motors, and the basic module includes Safe torque off, a brake chopper and coated boards.
Technical reference
| Product name | ABB ACS380-040S-05A6-4 Frequency Inverter |
|---|---|
| Brand | ABB |
| Model | ACS380-040S-05A6-4 |
| Category | Electrical, Power & Connectivity |
| Frame size | R1 |
| Supply voltage | 3-phase 380 to 480 V AC |
| Heavy-duty rating | 1.5 kW, 4.0 A |
| Light-duty rating | 2.2 kW, 5.3 A |
| ABB order code | 3AXD50000031890 |
| Product type | ACS380 machinery drive |
| Nominal motor power | 2.2 kW |
| Nominal output current | 5.6 A |
