ZYGO ZMI2401 ZMI 2400 Interferometer Measurement Board
- Brand
- ZYGO
- Model
- ZMI2401
- GEARWELL SKU
- GWP-000018883
- Category
- Test & Measurement
Key specifications
- Evidence
- ZYGO ZMI 2400 Measurement Board spec sheet (hosted at lambdaphoto.co.uk, ZYGO UK distributor)
- Board type
- VME 6U
- Position range
- ±10.6 m
- Position format
- 36 bit, 2's complement
- Maximum velocity
- 2.1 m/s
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | ZYGO ZMI2401 ZMI 2400 Interferometer Measurement Board |
|---|---|
| Brand | ZYGO |
| Model | ZMI2401 |
| Category | Test & Measurement |
| Evidence | ZYGO ZMI 2400 Measurement Board spec sheet (hosted at lambdaphoto.co.uk, ZYGO UK distributor) |
| Board type | VME 6U |
| Position range | ±10.6 m |
| Position format | 36 bit, 2's complement |
| Maximum velocity | 2.1 m/s |
| Power requirement | 5 VDC +0.25/-0.125 V @ 3.5 A max |
| Position resolution | λ/2048 (0.31 nm), double pass interferometer |
| Operating temperature | 10 to 55 °C |
| Time stamp resolution | 25 ns |
| Minimum input optical power | > 1.9 µW AC |
