YOKOGAWA AMM42T CENTUM CS 2-Wire Transmitter Input Multiplexer
- Brand
- YOKOGAWA
- Model
- AMM42T
- GEARWELL SKU
- GWP-000026733
- Category
- PLCs & I/O
Key specifications
- Series
- Also listed for CENTUM CS 3000 RIO in GS 33Y06K40-31E (only AMM42 variant listed: AMM42T)
- Type letter
- T (AMM42T is the only AMM42 model in GS 33Y06K40-31E; collected code had no type letter)
- Input signal
- 4 to 20 mA DC
- Accuracy rating
- ±16 µA
- Input resistance
- 250 ohm (70 ohm when connected to barrier)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YOKOGAWA AMM42T CENTUM CS 2-Wire Transmitter Input Multiplexer |
|---|---|
| Brand | YOKOGAWA |
| Model | AMM42T |
| Category | PLCs & I/O |
| Series | Also listed for CENTUM CS 3000 RIO in GS 33Y06K40-31E (only AMM42 variant listed: AMM42T) |
| Type letter | T (AMM42T is the only AMM42 model in GS 33Y06K40-31E; collected code had no type letter) |
| Input signal | 4 to 20 mA DC |
| Accuracy rating | ±16 µA |
| Input resistance | 250 ohm (70 ohm when connected to barrier) |
| Number of inputs | 16 |
| Signal isolation | Non-insulated between system and field, and between channels |
| Code as collected | AMM42 S4 |
| Data update period | 1 s |
| Style (as collected) | S4 |
| Transmitter power supply | 23.5 to 24.5 V DC (output limit 60 mA or less) |
