YOKOGAWA AAI143 FIO Analog Input Module 4-20 mA 16-Ch Isolated
- Brand
- YOKOGAWA
- Model
- AAI143
- GEARWELL SKU
- GWP-000026460
- Category
- PLCs & I/O
Key specifications
- Weight
- 0.3 kg
- Accuracy
- ±16 µA
- Evidence
- Yokogawa GS 33Q06Q40-31E Analog I/O Modules (for FIO), 24th ed. (library.yokogawa.com)
- Input signal
- 4 to 20 mA
- Input channels
- 16, isolated
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YOKOGAWA AAI143 FIO Analog Input Module 4-20 mA 16-Ch Isolated |
|---|---|
| Brand | YOKOGAWA |
| Model | AAI143 |
| Category | PLCs & I/O |
| Weight | 0.3 kg |
| Accuracy | ±16 µA |
| Evidence | Yokogawa GS 33Q06Q40-31E Analog I/O Modules (for FIO), 24th ed. (library.yokogawa.com) |
| Input signal | 4 to 20 mA |
| Input channels | 16, isolated |
| Suffix options | -S standard / -H HART; 5 no explosion protection / E with explosion protection; 0 basic / 3 ISA G3 + -20 to 70 °C (specify on order) |
| Data update period | 10 ms |
| Withstanding voltage | 1500 V AC between input and system, 1 min |
| Maximum current consumption | 230 mA (5 V DC), 540 mA (24 V DC) |
