VAISALA HMT120KB1A1E13A1A0Z HMT120 Humidity Temperature Transmitter
- Brand
- VAISALA
- Model
- HMT120KB1A1E13A1A0Z
- GEARWELL SKU
- GWP-000023120
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- 4...20 mA (position 4 = A)
- Positions 9-13
- A = no transmitter installation accessories; 1 = no probe installation kit; A = cable gland 2...6 mm; 0 = no PC accessories; Z = multilingual manual
- Code as collected
- HMT120KB1A1E13A1A0Z
- Output 1 (position 5)
- 1 = Channel 1 RH 0...100 %RH
- Output 2 (position 6)
- E = Temperature range T -40...+80 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | VAISALA HMT120KB1A1E13A1A0Z HMT120 Humidity Temperature Transmitter |
|---|---|
| Brand | VAISALA |
| Model | HMT120KB1A1E13A1A0Z |
| Category | Pressure, Flow & Temperature |
| Output | 4...20 mA (position 4 = A) |
| Positions 9-13 | A = no transmitter installation accessories; 1 = no probe installation kit; A = cable gland 2...6 mm; 0 = no PC accessories; Z = multilingual manual |
| Code as collected | HMT120KB1A1E13A1A0Z |
| Output 1 (position 5) | 1 = Channel 1 RH 0...100 %RH |
| Output 2 (position 6) | E = Temperature range T -40...+80 °C |
| Display units (position 7) | 1 = Metric units |
| Sensor protection (position 8) | 3 = Stainless steel sintered filter HM46670SP |
| Order code position 3 (display) | 1 = With display |
| Order code position 2 (transmitter type) | B = 3 m cable for remote probe (HMT120Z300) |
| Order code position 1 (output parameters) | K = Humidity and temperature, HMP110 stainless steel probe |
