VAISALA HMT120KB0A1E13A1A0Z HMT120 Humidity Temperature Transmitter
- Brand
- VAISALA
- Model
- HMT120KB0A1E13A1A0Z
- GEARWELL SKU
- GWP-000022591
- Category
- Pressure, Flow & Temperature
Key specifications
- Output 1
- 1 = Channel 1 RH 0...100 %RH
- Output 2
- E = Channel 2 T -40...+80 °C
- Display units
- 1 = Metric units
- Supply voltage
- 10...30 (RL=0 Ω) / 20...30 (RL<500 Ω) VDC
- Sensor protection
- 3 = Stainless steel sintered filter HM46670SP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | VAISALA HMT120KB0A1E13A1A0Z HMT120 Humidity Temperature Transmitter |
|---|---|
| Brand | VAISALA |
| Model | HMT120KB0A1E13A1A0Z |
| Category | Pressure, Flow & Temperature |
| Output 1 | 1 = Channel 1 RH 0...100 %RH |
| Output 2 | E = Channel 2 T -40...+80 °C |
| Display units | 1 = Metric units |
| Supply voltage | 10...30 (RL=0 Ω) / 20...30 (RL<500 Ω) VDC |
| Sensor protection | 3 = Stainless steel sintered filter HM46670SP |
| Order code position 1 | K = humidity and temperature, HMP110 stainless steel probe |
| Order code position 2 | B = 3 m cable for remote probe |
| Order code position 3 | 0 = No display |
| Order code position 4 | A (4...20 mA, fixed) |
| Probe installation kit | 1 = No accessories |
