TURCK WK 4T-2-PSG M12 Right-Angle to M8 Male Cordset 2 m
- Brand
- TURCK
- Model
- WK 4T-2-PSG
- GEARWELL SKU
- GWP-000023646
- Category
- Terminals, Cables & Connectors
Key specifications
- Cable
- TPU jacket, 3 x 22 AWG, 4.8 mm O.D.
- Ident no.
- U0919-08
- Connectors
- right-angled 4-pin M12 eurofast female + 3-pin M8 picofast male
- Cable length
- 2 m
- Rated current
- 4 A
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK WK 4T-2-PSG M12 Right-Angle to M8 Male Cordset 2 m |
|---|---|
| Brand | TURCK |
| Model | WK 4T-2-PSG |
| Category | Terminals, Cables & Connectors |
| Cable | TPU jacket, 3 x 22 AWG, 4.8 mm O.D. |
| Ident no. | U0919-08 |
| Connectors | right-angled 4-pin M12 eurofast female + 3-pin M8 picofast male |
| Cable length | 2 m |
| Rated current | 4 A |
| Rated voltage | 125 V AC |
| PSG variant options | PSG 3M / PSG 3M/S90/S771/SV (specify on order) |
| Degree of protection | IP68 |
| Maker identification | maker per distributor listings (shop.lakelandengineering.com, platt.com) |
| Full type designation (as titled) | WK 4T-2-PSG 3M/S90/S771/SV |
