TURCK TS-500-LUUPN8X-H1141 Temperature Sensor with Display
- Brand
- TURCK
- Model
- TS-500-LUUPN8X-H1141
- GEARWELL SKU
- GWP-000023137
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 6840016
- Voltage output
- 0...10 V
- Output function
- NO/NC programmable, PNP/NPN
- Housing material
- Stainless-steel/Plastic, 1.4305 (AISI 303)
- Type designation
- TS-500-LUUPN8X-H1141
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK TS-500-LUUPN8X-H1141 Temperature Sensor with Display |
|---|---|
| Brand | TURCK |
| Model | TS-500-LUUPN8X-H1141 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 6840016 |
| Voltage output | 0...10 V |
| Output function | NO/NC programmable, PNP/NPN |
| Housing material | Stainless-steel/Plastic, 1.4305 (AISI 303) |
| Type designation | TS-500-LUUPN8X-H1141 |
| Code as collected | TS-500-LUUPN8X-H1141 Turck 图尔克 温湿度产品 |
| Measuring element | For connection to TP series probes |
| Operating voltage | 18...30 VDC |
| Process connection | Cylindrical, Ø 18 mm |
| Electrical connection | Connector, M12 x 1 |
| Communication protocol | IO-Link |
| Temperature measuring range | -50...500 °C |
