TURCK BI1-G08-AP6X M8 Inductive Proximity Sensor PNP NO
- Brand
- TURCK
- Model
- BI1-G08-AP6X
- GEARWELL SKU
- GWP-000023169
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Threaded barrel M8 x 1, stainless steel 1.4404 (AISI 316L)
- Output function
- 3-wire, NO contact, PNP
- Protection class
- IP67
- Operating voltage
- 10...30 VDC
- Mounting conditions
- Flush
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK BI1-G08-AP6X M8 Inductive Proximity Sensor PNP NO |
|---|---|
| Brand | TURCK |
| Model | BI1-G08-AP6X |
| Category | Proximity & Photoelectric Sensors |
| Housing | Threaded barrel M8 x 1, stainless steel 1.4404 (AISI 316L) |
| Output function | 3-wire, NO contact, PNP |
| Protection class | IP67 |
| Operating voltage | 10...30 VDC |
| Mounting conditions | Flush |
| Switching frequency | 3 kHz |
| Rated switching distance | 1 mm |
| DC rated operational current | <= 150 mA |
| Electrical connection options | no connection code in collected type; BI1-G08-AP6X-H1341 (ident 46030) = M12 x 1 connector (specify on order) |
