TURCK BI1-EH04-RP6X-V1331 4 mm Inductive Proximity Sensor
- Brand
- TURCK
- Model
- BI1-EH04-RP6X-V1331
- GEARWELL SKU
- GWP-000023168
- Category
- Proximity & Photoelectric Sensors
Key specifications
- Housing
- Smooth barrel 4 mm, stainless steel 1.4305 (AISI 303)
- Ident no.
- 4608441
- Output function
- 3-wire, NC contact, PNP
- Protection class
- IP67
- Operating voltage
- 10...30 VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK BI1-EH04-RP6X-V1331 4 mm Inductive Proximity Sensor |
|---|---|
| Brand | TURCK |
| Model | BI1-EH04-RP6X-V1331 |
| Category | Proximity & Photoelectric Sensors |
| Housing | Smooth barrel 4 mm, stainless steel 1.4305 (AISI 303) |
| Ident no. | 4608441 |
| Output function | 3-wire, NC contact, PNP |
| Protection class | IP67 |
| Operating voltage | 10...30 VDC |
| Ambient temperature | -25...+70 °C |
| Switching frequency | 3 kHz |
| Electrical connection | Connector M8 x 1, 3-pin |
| Rated switching distance | 1 mm |
| DC rated operational current | <= 100 mA |
