TURCK 9910656 TTMS-203A-CF-LIUPN-H1140-L100 Temperature Transmitter
- Brand
- TURCK
- Model
- 9910656
- GEARWELL SKU
- GWP-000022982
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 9910656
- Current output
- 4...20 mA
- Factory setting
- 0...150 °C
- Output function
- NO/NC programmable, PNP/NPN
- Type designation
- TTMS-203A-CF-LIUPN-H1140-L100
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 9910656 TTMS-203A-CF-LIUPN-H1140-L100 Temperature Transmitter |
|---|---|
| Brand | TURCK |
| Model | 9910656 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 9910656 |
| Current output | 4...20 mA |
| Factory setting | 0...150 °C |
| Output function | NO/NC programmable, PNP/NPN |
| Type designation | TTMS-203A-CF-LIUPN-H1140-L100 |
| Code as collected | TTMS-203A-CF-LIUPN-H1140-L100 Turck 图尔克 其他 |
| Immersion depth (L) | 100 mm |
| Measuring element | Pt100, DIN EN 60751, class A |
| Operating voltage | 18...32 VDC |
| Pressure resistance | 100 bar |
| Communication protocol | IO-Link |
| Temperature measuring range | -70...500 °C |
