TURCK 9910655 TTMS-100-LIUPN-H1140/S713 Temperature Transmitter
- Brand
- TURCK
- Model
- 9910655
- GEARWELL SKU
- GWP-000022981
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 9910655
- Code note
- Seller wrote "TTMS-100A-LIUPN-H1140/S713"; the Turck datasheet for Ident-No. 9910655 gives type TTMS-100-LIUPN-H1140/S713 (no "A")
- Current output
- 4...20 mA
- Factory setting
- 0...150 °C
- Output function
- NO/NC programmable, PNP/NPN
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 9910655 TTMS-100-LIUPN-H1140/S713 Temperature Transmitter |
|---|---|
| Brand | TURCK |
| Model | 9910655 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 9910655 |
| Code note | Seller wrote "TTMS-100A-LIUPN-H1140/S713"; the Turck datasheet for Ident-No. 9910655 gives type TTMS-100-LIUPN-H1140/S713 (no "A") |
| Current output | 4...20 mA |
| Factory setting | 0...150 °C |
| Output function | NO/NC programmable, PNP/NPN |
| Type designation | TTMS-100-LIUPN-H1140/S713 |
| Code as collected | TTMS-100A-LIUPN-H1140/S713 Turck 图尔克 其他 |
| Measuring element | For connection to TP series probes |
| Operating voltage | 18...32 VDC |
| Process connection | M12 x 1 |
| Pressure resistance | 100 bar |
| Communication protocol | IO-Link |
| Temperature measuring range | -50...350 °C |
