TURCK 9910622 TTM-203A-CF-LIUPN-H1140-L150 Temperature Transmitter
- Brand
- TURCK
- Model
- 9910622
- GEARWELL SKU
- GWP-000022974
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 9910622
- Current output
- 4...20 mA
- Factory setting
- 0...150 °C
- Output function
- NO/NC programmable, PNP/NPN
- Type designation
- TTM-203A-CF-LIUPN-H1140-L150
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 9910622 TTM-203A-CF-LIUPN-H1140-L150 Temperature Transmitter |
|---|---|
| Brand | TURCK |
| Model | 9910622 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 9910622 |
| Current output | 4...20 mA |
| Factory setting | 0...150 °C |
| Output function | NO/NC programmable, PNP/NPN |
| Type designation | TTM-203A-CF-LIUPN-H1140-L150 |
| Code as collected | Turck 图尔克TTM-203A-CF-LIUPN-H1140-L150温度传感器 |
| Immersion depth (L) | 150 mm |
| Measuring element | Pt100, DIN EN 60751, class A |
| Operating voltage | 8...32 VDC |
| Pressure resistance | 100 bar |
| Communication protocol | IO-Link |
| Temperature measuring range | -50...350 °C |
