TURCK 9910549 TTM100C-103A-G1/8-LI6-H1140-L013 Temperature Transmitter
- Brand
- TURCK
- Model
- 9910549
- GEARWELL SKU
- GWP-000022973
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 9910549
- Current output
- 4...20 mA
- Housing material
- Stainless-steel/Plastic, 1.4404 (AISI 316L)
- Type designation
- TTM100C-103A-G1/8-LI6-H1140-L013
- Code as collected
- TTM100C-103A-G1/8-LI6-H1140-L0 13 Turck 图尔克 其他
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 9910549 TTM100C-103A-G1/8-LI6-H1140-L013 Temperature Transmitter |
|---|---|
| Brand | TURCK |
| Model | 9910549 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 9910549 |
| Current output | 4...20 mA |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L) |
| Type designation | TTM100C-103A-G1/8-LI6-H1140-L013 |
| Code as collected | TTM100C-103A-G1/8-LI6-H1140-L0 13 Turck 图尔克 其他 |
| Immersion depth (L) | 13 mm |
| Measuring element | Pt1000, DIN EN 60751, class A |
| Operating voltage | 5.5...32 VDC |
| Process connection | G 1/8″ male thread |
| Pressure resistance | 100 bar |
| Electrical connection | Connector, M12 x 1 |
| Temperature measuring range | 0...100 °C |
