TURCK 9910402 TP-203A-CF-H1141-L100 Pt100 Temperature Probe
- Brand
- TURCK
- Model
- 9910402
- GEARWELL SKU
- GWP-000022967
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 9910402
- Housing material
- Stainless steel, 1.4404 (AISI 316L)
- Protection class
- IP67
- Type designation
- TP-203A-CF-H1141-L100
- Code as collected
- Turck 图尔克TP-203A-CF-H1141-L100温度传感器
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 9910402 TP-203A-CF-H1141-L100 Pt100 Temperature Probe |
|---|---|
| Brand | TURCK |
| Model | 9910402 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 9910402 |
| Housing material | Stainless steel, 1.4404 (AISI 316L) |
| Protection class | IP67 |
| Type designation | TP-203A-CF-H1141-L100 |
| Code as collected | Turck 图尔克TP-203A-CF-H1141-L100温度传感器 |
| Immersion depth (L) | 100 mm |
| Measuring element | Pt100, DIN EN 60751, class A; connection mode: 4-wire connection |
| Process connection | For compression fittings, thermowell or direct mounting |
| Ambient temperature | -40...+120 °C |
| Pressure resistance | 100 bar |
| Electrical connection | Connector, M12 x 1 |
| Temperature measuring range | -50...500 °C |
