TURCK 9910400 TP-103A-G1/8-H1141-L013 Pt100 Temperature Probe
- Brand
- TURCK
- Model
- 9910400
- GEARWELL SKU
- GWP-000022966
- Category
- Pressure, Flow & Temperature
Key specifications
- Ident-No.
- 9910400
- Housing material
- Stainless steel, 1.4404 (AISI 316L)
- Protection class
- IP67
- Type designation
- TP-103A-G1/8-H1141-L013
- Code as collected
- Turck 图尔克TP-103A-G1/8-H1141-L013温度传感器
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | TURCK 9910400 TP-103A-G1/8-H1141-L013 Pt100 Temperature Probe |
|---|---|
| Brand | TURCK |
| Model | 9910400 |
| Category | Pressure, Flow & Temperature |
| Ident-No. | 9910400 |
| Housing material | Stainless steel, 1.4404 (AISI 316L) |
| Protection class | IP67 |
| Type designation | TP-103A-G1/8-H1141-L013 |
| Code as collected | Turck 图尔克TP-103A-G1/8-H1141-L013温度传感器 |
| Immersion depth (L) | 13 mm |
| Measuring element | Pt100, DIN EN 60751, class A; connection mode: 4-wire connection |
| Process connection | G 1/8″ male thread |
| Ambient temperature | -40...+120 °C |
| Pressure resistance | 100 bar |
| Electrical connection | Connector, M12 x 1 |
| Temperature measuring range | -50...120 °C |
